卷簾門能起到水平分割的作用，就像墻的作用是一樣的，一些商業門面，車庫等地方都可以用到卷簾門，開啟也比較方便，濟南卷簾門的大軸是如何安裝的呢？

Rolling shutter doors can serve as horizontal partitions, just like walls. Some commercial storefronts, garages, and other places can use rolling shutter doors, which are also more convenient to open. How is the large axis of Jinan rolling shutter doors installed?

一：在安裝卷簾門的大軸時，要先將掛板定好方向，并安裝到卷軸上，再用簾板裝到掛板上，在卷在卷軸上用鐵絲扎牢固。

1： When installing the large axis of the roller shutter door, the hanging plate should be oriented and installed on the roller first. Then, the curtain plate should be installed on the hanging plate, and firmly tied with iron wire on the roller.

二：安裝時先將套上軸承及座的光軸塞入卷軸的端孔中，對準位置后再將軸承固定螺栓擰緊，在卷軸上好之后，可以左右移動下卷筒調節位置。

2： When installing, first insert the optical shaft with the bearing and seat into the end hole of the winding shaft, align it with the position, and then tighten the bearing fixing bolts. After the winding shaft is installed, the lower drum can be moved left and right to adjust the position.

三：調整好位置后，光軸和卷軸固定好，光軸和軸承要用支頭螺釘固定好，卷軸在吊裝時要注意下不要碰壞軸上的簾板，可以用鋼絲繩捆扎下。

3： After adjusting the position, the optical axis and the roller are fixed, and the optical axis and bearings should be fixed with support screws. When lifting the roller, be careful not to damage the curtain board on the shaft, and it can be tied with steel wire ropes.

安裝注意事項

Installation precautions

1.在安裝卷簾門前，觀察卷簾機是否水平安裝，卷簾軸是否光滑，是否有滯卡現象，如有，應及時處理。

Before installing the roller shutter door, observe whether the roller shutter machine is installed horizontally, whether the roller shutter shaft is smooth, and whether there is any jamming. If there is any, it should be dealt with in a timely manner.

2.窗簾掛起前，應調整鏈條的下垂度，以滿足標準要求。

Before hanging the curtains, the sag of the chain should be adjusted to meet the standard requirements.

3.卷門機與外部電源線接觸的截面尺寸有一定要求，不小于1平方毫米。

3. There are certain requirements for the section size of the door winder in contact with the external power line, which is not less than 1 square millimetre.

4.在安裝的過程中一定要注意防潮，不要被雨淋，接觸水后容易使卷門機電器短路，會使卷簾門電機燒壞，影響正常使用。

4. During the installation process, it is necessary to pay attention to moisture-proof measures and avoid being exposed to rain. Contact with water can easily cause a short circuit in the electrical equipment of the rolling door machine, which can cause the motor of the rolling door to burn out and affect normal use.

5.連接電源時，不要反向連接電源。當電源上升并下降時，機器應立即停止工作，協調順序，并正常工作。否則會損壞卷簾門的正常使用。

5. When connecting the power supply, do not connect it in the opposite direction. When the power supply rises and falls, the machine should immediately stop working, coordinate the sequence, and operate normally. Otherwise, it will damage the normal use of the roller shutter door.

當我們安裝卷簾門時，我們需要注意很多細節，所以我們需要對安裝方法有一定的了解，只有這樣我們才能更好地安裝。還有什么事項隨時來咨詢我們http://m.santoncc.cn！

When installing roller shutter doors, we need to pay attention to many details, so we need to first have a certain understanding of the installation method, so that we can better install it. Feel free to consult us on any other matters http://m.santoncc.cn !
